1. Main technical performance indicators

Working power supply: AC220V ± 22V 50Hz ± 1Hz

Power: 2000W

Air flow: ≥20m3 / h

Sterilization volume: ≤550m3

Injection rate: 1 ～ 20g / min

Outlet temperature: ≤100 ℃

Sterilizer: 35% food grade hydrogen peroxide solution

Killing rate: the killing ability of thermophilic fat spores reaches 106

Working mode: continuous work

Dimensions: 400mm × 400mm × 970mm (length × width × height)

Weight: 45Kg

2. The use requirements

Working power supply: AC 220V ± 22V, frequency 50Hz ± 1Hz.

Ground wire requirements: effective grounding, grounding impedance ≤4Ω.

Ambient temperature: 20 ℃ ～ 30 ℃

Relative humidity: ≤80% RH

Cleanliness requirements: clean the space and control the entry and exit of irrelevant personnel.

Main features

1. The maximum sterilization space of a single host can reach at least 550 cubic meters;

2. Power supply AC220V ± 22V, frequency 50Hz ± 1Hz, power ≤2500 W

3. The dual-screen control system is adopted, which can be controlled by the built-in LCD screen. Standard PC software can be controlled through a remote computer control system. A remote computer can control at least 3 single-point generator devices at the same time.

4. The sterilizer has wireless or wired communication function, and can be connected to the remote monitoring terminal through terminal routing. The host computer software can remotely monitor the sterilization status, temperature, humidity and hydrogen peroxide concentration in real time; the monitoring data can be file Output and print

5. The main unit of the device has built-in temperature, humidity and hydrogen peroxide concentration probes. During the sterilization process, the disinfectant injection rate can be adjusted in real time according to the temperature and humidity of the room and the concentration of hydrogen peroxide; external multi-point temperature and humidity collection sensors can also be selected. Hydrogen peroxide concentration sensor, used for verification and recording of work sterilization effect.

6. The built-in weighing module can control the total spraying amount of the sterilization process to avoid the phenomenon that the sterilization effect is not ideal due to excessive spraying and insufficient spraying.

7. With printing function, the current working status and temperature and humidity information can be printed in real time during sterilization, for querying the working status after sterilization is completed.

8. The device itself has a U disk data export function, which can export and store the corresponding sterilization records

Remote operation

• The upper computer software is installed on the external interface (personal computer, laptop, tablet, iPad) with fixed IP address

• Switches, routers, hubs

• Ethernet cable

• V200 biological purification unit

Determine the wired or wireless connection according to the actual situation of the user.

Concentration feedback

• The adjustment stage quickly raises the concentration of disinfectant in the isolation area to the set value, followed by the biological sterilization stage.

• When the set time of the set concentration of the bactericide is reached, the sterilization stage is enough.

• Then enter the ventilation stage.

Biological decontamination process

Stage 1: Dehumidification, reduce the relative humidity in the air to the preset value;

Stage 2: Adjust, quickly increase the concentration of hydrogen peroxide gas in the space;

Stage 3: Maintain and maintain the concentration of hydrogen peroxide gas required for the biological decontamination of the space; Stage

Stage 4: Ventilate and remove residues, and exclude hydrogen peroxide gas and water vapor in the space
